Product Parameter |
Parameter Description |
Dimensions |
90Lx35Wx20H(mm) |
Voltage |
12V |
Current |
Standby 20mA |
Output Contact |
NO/COM |
Current Rating |
1A@30VDC 0.5A@125VDC |
Operating Temperature |
-20℃~50℃ |
Operating Humidity |
0%~99% |
Waterproof Level |
IP-68 |
Wire color |
Red: Positive Black: Negative |
LED Status |
RED:Standby GREEN:Operation |
Weight |
0.18kg |
Certification |
CE-EMC CE-LVD FCC-VOC REACH WEEE |
Stainless steel Panel with Elegant Style.
100000 Cycles tests.
Three Contact Output,Suitable for all kinds of Locks.
The Best Choice for Access Control.
Warranty Service will be honored if the damage is not caused by human, YLI Provides 1 years warranty for relative products. On the contrary, YLI will charge extra if repair. More information, please browse our service centre.
YLI Company retains right to modify the specification of products, and for parameters amendment of products, we will not inform in advance. The relative pictures are not allowed to used in any other way without the consent of YLI Company. Meanwhile, we reserved all the rights of law for any tangle.
