Product Parameter |
Parameter Description |
Lock Size |
140Lx43.5Wx47H |
Static strength |
1000lbs |
Magnetic Valve |
500000 times |
Voltage |
12VDC(Available DC24V) |
Current |
280mA |
Feature |
Fail Safe/Fail Secure(Adjustable) |
Suitable For |
Wooden Door,Metal Door,PVC Door |
Operating Humidity |
0~95%(non-condensing) |
Weight |
0.6kg |
Certification |
MA CE-EMC FCC RoHS |
Fail safe or fail secure reversible
Left-way opening or right-way opening installation adjustable
Stainless steel bolt,304 stainless steel faceplate
Max static pressure holding force is 1000 lbs
Magnetic valve duration>500000 times
Warranty Service will be honored if the damage is not caused by human, YLI Provides 1 years warranty for relative products. On the contrary, YLI will charge extra if repair. More information, please browse our service center.
YLI Company retains right to modify the specification of products, and for parameters amendment of products, we will not inform in advance. The relative pictures are not allowed to used in any other way without the consent of YLI Company. Meanwhile, we reserved all the rights of law for any tangle.
Packing Quantity(PCS/CTN) |
|
Packing Size(L*W*H)(cm) |
|
Gross Weight(KG) |
|
coming soon
