Product Parameter |
Parameter Description |
Dimension |
195Lx25WX42.5H(mm) |
Keeper |
Thickened Zinc Alloy |
Preload |
200kg |
Static strength |
400kg |
Voltage |
DC12V (Available DC24V) |
Current |
12V/260mA(±10%) ; 24V/130mA(±10%) |
Signal output |
NO/NC/COM lock signal output |
Suitable For |
Wooden door; Metal door;PVC door |
Surface Temperature |
Lower than room temperature +20℃ |
Operating temperature |
-10~+60℃(14-131F) |
Humidity |
0~95%(non-condensing) |
Finishing |
High Temperature Lacquer |
Weight |
0.5kg |
Certification |
CE-EMC RoHS |
Holding 400kg.
Special design,easy to adjust the distance of the Lock-tongue.
Designed for Metal Frame drill a hole,then install it directly.
Testing to 2500000 cycles.
High-Temperature Painted,Duable and Beatiful Artical.
CE Certificate by European Union, MACertificate by China Public Security office.
Warranty Service will be honored if the damage is not caused by human, YLI Provides 3 years warranty for relative products. On the contrary, YLI will charge extra if repair. More information, please browse our service center.
YLI Company retains right to modify the specification of products, and for parameters amendment of products, we will not inform in advance. The relative pictures are not allowed to used in any other way without the consent of YLI Company. Meanwhile, we reserved all the rights of law for any tangle.
